| Attribute | Value |
|---|---|
| AC or DC Output Voltage | Dc |
| Input Voltage | 85 → 264 V ac, 120 → 370 V dc |
| Output Voltage | 5 V dc |
| Output Current | 2.4 A |
| Power Rating | 12W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Height | 90mm |
| Width | 17.5mm |
| MTBF | 1166kh |
| Ripple And Noise | 80mV Pk-Pk |
| Minimum Temperature | -30°C |
| Depth | 54.5mm |
| Mounting Type | DIN Rail |
| Special Features | Small & Compact |
| Series | HDR |
| Standards Met | RoHS Compliant, TUV EN 60950-1, UL 508 |
| Maximum Temperature | +70°C |
| Output Voltage Adjustment Range | 4.5 → 5.5V |
| Load Regulation | ±1% |
